Function:

1, Test common rail injector: (BOSCH, DENSO, SIEMENS, DELPHI, CUMMINS, CAT, etc, including CUMMINS ISG/XPI injector,4 pin injector).

2, Test piezoelectric injector

3, Test the injector's inductance and resistance

4, QR coding(injector coding for Bosch, Denso, Siemens, Delphi, Cummins…)

5, BIP for common rail injector(Optional)

6.All data can be searched, printed

7.Can connect to WIFI and upgrade test data for free. Also be operated remotely by teamviewer.

Technical parameter:
1.Industrial computer system, 17 inch color LCD touch screen control, easy to operate, stable performance.

2.The BOSCH CP3.3 pump is configured.

3. Input power: Voltage three-phase 220V / 380V voltage, for you to choose.

4. Motor speed range: 0-4000RPM.

5. BOSCH high pressure valve. pressure range 0-2400BAR. Rail pressure accuracy ±0.5 bar

6. Good quality China gear flowmeter for injector testing.Accurate testing, reliable and stable use.

Flow measurement accuracy:0.1ml,Flow testing range: 0-600ml/1000times
